Trek Fuel EX 5 Gen 7

Trek Fuel EX 5 Gen 7
Trek Fuel EX 5 Gen 7 Trek Fuel EX 5 Gen 7 Trek Fuel EX 5 Gen 7 Trek Fuel EX 5 Gen 7 Trek Fuel EX 5 Gen 7

Product Details

Fuel EX has always been our most versatile full-suspension bike, giving riders an award-winning trail feel wherever they roll. Now, Fuel has been updated with a new frame design that maximizes versatility without any compromises on performance. With interchangeable rocker links and lower shock mounts, the all-new Fuel transforms into three configurations, adapting to different terrain and riding styles, so you can dial in your customer no matter how they ride or where they roll.

The Fuel EX 5 is an aluminium trail bike built for total versatility wherever you ride. It comes with a RockShox Recon Silver fork and X-Fusion Pro 2 rear shock, Tubeless Ready wheels, a 12-speed Shimano Deore drivetrain and a TranzX dropper post, so you're ready for anything.

  • The new frame design on Fuel lets most size M riders run a 200mm dropper
  • Tons of room for big water bottles, spare tubes, or additional accessories like frame bags or mini-pumps
  • Fuel now utilizes the ZS internal headset standard to allow for more aftermarket options like angle-adjust headset
  • Riders can tweak leverage rate with the flip of a chip
  • Stash ride essentials with in-frame storage on all Fuel models, top tube accessory mounts let you load up even more
Frame Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145-160mm
Fork Rockshox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock X-Fusion Pro 2, 2-position damper, 205 mm x 60mm
Hub front Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear Bontrager Switch thru-axle, removable lever
Rim Bontrager Line TLR 30, Tubeless-Ready, F-28H, R-32H, Presta valve
Tyre Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40" (S=27.5x2.4" rear)
Tyre part Bontrager TLR sealant, 180ml
Rim strip Bontrager TLR
Shifter Shimano Deore M6100, 12-speed
Rear derailleur Shimano Deore M6100, long cage
Crank Shimano MT512, 30T ring, 55 mm chain line, 170 mm length
Bottom Bracket Shimano BB-MT501 BSA
Cassette Shimano Deore M6100, 10-51, 12-speed
Chain Shimano Deore M6100, 12-speed
Saddle Bontrager Verse P3, chromoly rails
Seatpost

TranzX JD-YSI34, S-150mm, M/L/XL-170mm
Handlebar Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips Trek Line Comp, nylon lock-on
Stem Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Head set FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown
Brake Shimano hydraulic disc, MT201 lever, MT200 calliper
Brake rotor Shimano RT10, CenterLock, 180 mm
Weight M - 17.02 kg/34.51 lb (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
* Specifications subject to change without notice.

About Trek
From small beginnings [Trek was started in a barn in Waterloo, Wisconsin, in 1976] to becoming a giant in the industry. Their range of products covers every aspect of cycling, from kids bikes to competitive race machines, commuter bikes to high-tech e-bikes.



Product Code 5335769
